Hydraulic Press Manufacturer · 40+ Years of Metal Forming Experience
C-frame and H-frame hydraulic presses for a wide variety of sheet metal forming and deep drawing applications. Fully CE-compliant, engineered to order for special projects.
| Hydraulic press | Mechanical press | |
|---|---|---|
| Force source | Hydraulic fluid pressure (pump + cylinder) | Flywheel + crank or eccentric mechanical linkage |
| Force through the stroke | Full rated tonnage available at any point in the stroke | Peak force concentrated near bottom dead center |
| Tonnage & stroke | Programmable - adjust pressure, stroke length and speed per job on the same machine | Fixed by the machine's rated capacity and crank geometry |
| Cycle speed | Slower - governed by hydraulic flow rate | Faster - suited to high-volume repetitive strokes |
| Best suited for | Deep drawing, flexible or varied part runs, thicker or harder-to-form material | High-speed blanking and stamping of consistent parts, long production runs |
Neither type is strictly “better” - they're optimized for different production profiles. If your process is a fixed, high-volume stamping or blanking operation, a mechanical press generally gives faster cycle times at lower cost per part. If your process involves deep drawing, varies between jobs, or needs precise, programmable control over force and stroke, a hydraulic press is the more capable tool. Fresan manufactures both architectures, so this comparison is about picking the right machine for your process - see our mechanical press range alongside the hydraulic range above.
Hydraulic presses are particularly preferred when a three-dimensional component is to be manufactured from flat sheet metal in a controlled forming process, instead of welding or assembling it from multiple parts. Typical applications include:
sinks, pots, and pans drawn from stainless steel or aluminum blanks.
washing machine drums, panels, and enclosures.
body panels, fuel tanks, and structural brackets.
formed sheet-metal housings and transitions.
straightening, forming, and press-fit assembly work in job shops and OEM production lines.
The right press for each of these depends on part depth, material thickness and grade, and production volume - see the comparison above and the C-Frame and Deep Drawing pages for the tonnage and table-size ranges each line covers.
Every Fresan hydraulic press - C-Frame and H-Frame alike - is designed and built to meet CE marking requirements under the EU Machinery Directive (2006/42/EC), Low Voltage Directive (2014/35/EU), and EMC Directive (2014/30/EU), with electrical, hydraulic, and control components sourced from globally-recognized suppliers. Standard safety features include a dedicated safety controller, light curtains around the worktable, two-hand and foot-pedal interlocked controls, and an overpressure/safety relief valve. Every press also runs on centralized lubrication, reducing manual maintenance and keeping wear-critical components consistently lubricated. CE conformity is certified by TÜV.
Tell us your tonnage, configuration, and process requirements - we'll recommend the right hydraulic press for your application.
