30 Ton Eccentric Press – FP 30P
The FP 30P is the fourth of our five flywheel-driven models, rated at 30 tons. At 140 strokes per minute in continuous operation, it delivers strong throughput for mid-tonnage sheet metal work. Its 0 - 60 mm stroke range and 400 x 600 mm table allow for larger dies than the smaller models in the range. Standard equipment - AC inverter, built-in auxiliary cams, PLC-controlled central lubrication - means it's ready for servo or pneumatic feeder integration out of the box. Like every Fresan press, it's CE marked and built for years of continuous production use.
Technical Specifications
Complete technical specifications for the FP 30P. All values in millimetres unless noted - use the toggle to switch to inches.
| Model | FP 30P |
|---|---|
| Nominal Force (kN) | 300 |
| Rated Output Distance (mm) (from BDC) †Rated Output Distance (in) (from BDC) † | 2.00.08 |
| Stroke Adjustment (mm)Stroke Adjustment (in) | 0 - 600 - 2.36 |
| Ram Adjustment (mm)Ram Adjustment (in) | 602.36 |
| Strokes per Minute (SPM) | 140 |
| Daylight (mm) ††Daylight (in) †† | 30512.01 |
| Table Dimensions (mm)Table Dimensions (in) | 400 x 60015.75 x 23.62 |
| Ram Surface (mm)Ram Surface (in) | 380 x 25514.96 x 10.04 |
| Shank Hole (⌀ mm)Shank Hole (⌀ in) | 401.57 |
| Center Depth (mm) †††Center Depth (in) ††† | 2007.87 |
| Air Pressure (Bar) | 4-6 |
| Weight (kg)Weight (lb) | 16703680 |
| Table Thickness (mm)Table Thickness (in) | 652.56 |
| Table Bore (⌀ mm)Table Bore (⌀ in) | 752.95 |
† Rated output distance from the bottom dead center (BDC) at which the nominal force is reached.
†† Daylight: maximum distance between ram and table (ram at uppermost position).
††† Distance from the center of the table to the c-frame.
Standard Equipment
Safety Features
- •Conformity to CE safety regulations
- •Safety controller
- •Double body press safety valve
- •Light curtains around worktable
- •Covers with safety switches
- •Mechanical fuse for overload protection
Construction & Drive Mechanics
- •Welded steel frame, engineered for high rigidity
- •Crankshaft made of AISI 4140 (42CrMo4) alloy steel, CNC ground for min. surface friction
- •SnBz-12 quality bronze bushings
- •Direct flywheel drive
- •Pneumatic clutch-brake combination
- •Ram with 4 sliding surfaces
Control & Operation
- •AC inverter (standard on all models)
- •Automatic central lubrication (PLC-controlled)
- •Used oil collectors
- •HMI/touchscreen operator panel
- •2-hand & foot pedal control
- •Automatic cyclic mode with light curtains
- •Vibration pads/shock absorbers
Optional Equipment
Available extras and automation options
- •Additional worktable
- •Part ejector mechanisms (upper and/or lower ejectors)
- •Material feeding, loading & unloading systems (Decoilers, straighteners, pneumatic & servo feeders...)
- •Special design
